Waterproof IR Touch Frame 17"(TE)

Product Overview
GreenTouch TE series waterproof infrared touch screen is suitable for standard size LCD screen equipment or special equipment that needs to achieve waterproof effect. This product can achieve IP65 waterproof and dustproof, can withstand the sun and rain for a long time, can resist light at all angles, and can operate the touch function normally under strong light. This series of infrared touch frames have self-developed programs and the latest algorithms, with USB2.0+UATR interface plug-and-play, support IPA (software interface) and driver-free, and are widely used in self-service vending machines, outdoor smart charging piles, outdoor advertising all-in-one machines, outdoor inquiry machines, self-service express cabinets and other outdoor waterproof equipment.

       Product Advantages
♦ Multi-touch: 10-point infrared touch, quick response and no drift, no jumping;
♦ IP65 waterproof and dustproof: can be used in outdoor environments and complex industrial environments;
♦ Level 3 anti-static: tested in accordance with EN 6100-4-2 2008: Level 3;
♦ All-angle light resistance: light resistance 8000Lux, touch function can be operated normally under strong light;.
♦ Strong explosion-proof: Fully tempered glass cover, easily cope with violent impact, can well protect LCD devices;
♦ High humidity and high temperature operation: can operate normally at -15℃~55℃ temperature and 10%~90%RH (no condensation) humidity.

   Product Structure
GreenTouch TE series waterproof infrared touch screen adopts the structure of one-piece injection-molded light-transmitting frame + waterproof glue + mechanized glass bonding process, and the ultra-narrow frame thickness is only 8mm; advanced wick, LED infrared transmitting and receiving tubes, can draw smooth and accurate curves, and the failure of individual LED tubes will not affect the use effect.

       Product Features
USB2.0+UATR interface, supports API (software interface); alloy plug plug and play USB recognition time increased by 3 times, transmission speed 480mbps. Support Windows, Android, Linux and Mac operating systems

   Product Custom
1. Screen customization
→ Surface treatment (AG/AF/AR), size, glass thickness customization
2. Appearance customization
→ LOGO, frame color/size/material and other appearance customization
3. Special environment customization
→ High and low temperature environment, high humidity environment, interference environment, other environment customization

Engineering Drawing:GT-IR-TE21.5




Product Applications

GreenTouch TE series waterproof infrared touch screens are widely used in self-service vending machines, outdoor smart charging piles, outdoor advertising all-in-one machines, outdoor query machines, self-service express cabinets and other outdoor waterproof equipment.

Product Parameters:
